CertaFlux LED Panel The ultra-slim CertaFlux LED panels enable an easy and economical solution for commercial spaces and buildings. With a wide choice of drivers different light levels can be achieved. It’s different sizes (60x60; 62x62; 30x120; 60x120) makes it suitable for a wide range of ceilings. CertaFlux LED panels offer a good product performance (100 lm/W at 4000K CRI80) and reliability (30,000 hours). Key features and benefits • Efficacy up to 100 lm/W on module level • Ultra-slim LED module • Excellent light uniformity • Good color rendering (CRI >80) • Flexible lumen output due to wide driver choice • 3 years system warranty • Quick install connector is integrated • Wide range of dimensions: 60x60; 62x62; 30x120; 60x120

Ordering data Commercial product name EOC 12NC Box quantity CertaFlux LED Panel 30120 830 MD2 75173900 9290 021 66106 10 CertaFlux LED Panel 30120 840 MD2 75174600 9290 021 66206 10 CertaFlux LED Panel 30120 865 MD2 75175300 9290 021 66306 10 Drive currents Parameter Nominal* Life** Max*** Unit CertaFlux LED Panel 30120 800 1050 1150 mA Module temperatures Parameter Nominal* Life** Max*** Unit Tc (case temperature at Tc point) 45 65 75 °C * Nominal value at which typical performance is specified ** Value at which life time is specified *** Maximum value for safe operation, do not operate above this value
